LaserPecker LP3: Hochpräziser Lasergravierer für Metall und Kunststoff

€1.269,00 - €1.499,00
Preisangabe inkl. MwSt. & Kostenloser Standardversand
Tage
:
Std
:
Min
:
Sek

Jetzt bis zu 30% Rabatt sichern & Wunderschöne Projekte für diesen Sommer erstellen

Schneller & Kostenloser Standardversand von lokalem Lagerhaus

Metall & Kunststoff-Gravierer: LaserPecker LP3 ist eine Infrarot-Lasergravurmaschine speziell für Metall, Kunststoff und Kunstleder, kann z.B. Gold, Silber, Kupfer, Edelstahl, Titan, ABS-Kunststoff, Kunstleder gravieren.

4K Ultra-hohe Präzision: Bis zu 4K Auflösung und 0,01MM ultrafeinen Laserpunkt sorgen für ultrahöhe Gravurgenauigkeit und perfekte Bildwiedergabe.

Hochgeschwindigkeits-Gravur: Innovativer Galvanometer-Technologie in Industriequalität trägt zu einer Hochgeschwindigkeitsgravur von 36000mm/min bei. Sie können damit mehr Werke in kürzerer Zeit erledigen.

Einfache Dual-Rotlicht-Fokussierung: Keine komplizierte manuelle Messung. Mit nur einem Knopfdruck können Sie die Brennweite anpassen, bis die zwei roten Lichtpunkte sich übereinstimmen.

Unbegrenzte Gravur: Unbegrenzt von Zeit, Ort oder Winkel, einfach aufbauen und benutzen. 360°-Drehung für Multiwinkel-Gravur auf schrägen Objekten. Bringen Sie noch eine Powerbank mit, um flexible Gravur auf der Reise zu realisieren.

Rundum-Schutz: Das Laserschutzgehäuse kann die Laserstrahlung effektiv filtern und bietet Ihnen und Ihren Begleitern ein Höchstmaß an Vollschutz.

Option: LP3 + Schutzgehäuse
Normaler Preis €1.269,00
Verkaufspreis €1.269,00 Normaler Preis €1.699,00
-€430,00
Kostenlose Lieferung
12 Monate Garantie
Sicherer Checkout
Sichere Bezahlung
  • PayPal
  • Visa
  • MasterCard
  • Maestro
  • Klarna
  • American Express
  • Diners Club International
  • Discover
Zuverlässige Lieferung
  • DHL
  • GLS
  • DPD
LaserPecker LP3 Lasergravierer mit Schutzgehäuse Basic-Set
Normaler Preis €1.269,00
Verkaufspreis €1.269,00 Normaler Preis €1.699,00
LaserPecker LP3 - Geboren für Schmuck- und Kunststoffverarbeitung01-LP3KV-WAP.jpg__PID:13d4a5f9-c50c-40f7-b624-0dad5c943a80

100+ Materialien verarbeiten

LaserPecker LP3 kann Metalle wie Aluminium, Edelstahl, Platin, Silber, Gold, Kupfer, Messing usw. verarbeiten.LaserPecker LP3 kann Metalle wie Aluminium, Edelstahl, Platin, Silber, Gold, Kupfer, Messing usw. verarbeiten.laserpecker_lp3_lasergravierer_kunststoff_gravieren  LaserPecker LP3 kann Kunststoffe wie Acryl, Silikon, ABS, PVC, Acedat, Kunstleder usw. verarbeiten.LaserPecker LP3 kann Kunststoffe wie Acryl, Silikon, ABS, PVC, Acedat, Kunstleder usw. verarbeiten.

Erstaunliche Werke schaffen

LP3 für Schmuckherstellung und -individualisierungLP3 für Schmuckherstellung und -individualisierung

Fortschrittliche komprimierte
Spot-Technologie

Durch den Einsatz einer industrietauglichen Laserspot-Kompressionstechnologie erreicht LaserPecker LP3 einen ultrafeinen Laserpunkt von nur 0,01 mm und ermöglicht so einen Sprung in der Gravurgenauigkeit.

4K Realistische Details

Realistische Gravurqualität mit einer hohen Auflösung von bis zu 4K, stellt alle winzigen Details von Fotos klar wieder her.

0,01 mm Gravur-Genauigkeit

Hohe Gravurpräzision, feiner als Haare, die jedes subtile Detail der gravierten Muster perfekt zur Geltung bringt.

LaserPecker LP3 mit ultraschneller Gravurgeschwindigkeit von 800mm/sLaserPecker LP3 mit ultraschneller Gravurgeschwindigkeit von 800mm/s

Schnelleres Gravieren Effizienteres Arbeiten

Steigern Sie Ihre Produktivität um 250 %.

Mehr kreative
Gravurmöglichkeiten
entdecken

Zylindergravur mit vielseitiger Rotationswalze

Stapeln Sie Ihre Projekte mit der Positioniervorrichtung

Einfach drehen für
Multi-Winkel-Gravuren

Einfache Bedienung, Keine Lernkurve

Benutzerfreundliche Fokussierung und Projektvorschau

Intelligenter Doppelpunkt-Fokus

Drücken Sie die Taste oder tippen Sie einfach in der App, um die Höhe des Laserkopfes anzupassen, bis sich die beiden roten Punkte überschneiden.

Projektvorschau

Zeigen Sie das Projekt in der Vorschau genau an der Position an, die graviert werden soll.

Leistungsstarke Software, mühelos erstellen

Ihre erste Kreation in 3 einfachen Schritten erstellen

3 Schritten zur einfacher Gestaltung mit LP3

01 - Design

Einzigartige Designs im LaserPecker Design Space entwerfen

Design via LDS

02 - Gravieren

Die Objekte auf der Grundplatte legen und die Gravur starten

Schritt 2: Gravieren mit LP3

03 - Bewundern

Die hervorragenden Ergebnisse bewundern und viel Spaß damit!

Schritt 3: Ihre Werke bewundern

Extra-Schutz hinzufügen mit Laserschutzgehäuse

LP3 Projekt-Galerie

Trinkbecher mit Mustergravur, gelasert mit LP3

lori_laris_welt

Heute mal maritime Gravur 🤗⚓️Becher, Thermoflasche und einen Flachmann 😋🏖 Habt einen schönen Tag!

Metallanhänger mit Fotogravur, gelasert mit LP3

Calvin Forbes

Unedited photo of LP3 in 4K/100/65/1 (greyscale mode).

Namenschild mit Textgravur, gelasert mit LP3

Erinn LaMattery

And finally, a little Father's Day project I've been developing for my shop, so cute!

Kopfhörergehäuse mit Logogravur, gelasert mit LP3

Ernest Hui

First test on sacrificial old case (4K, 100,5,1) Looks amazing

Netzteil mit Mustergravur, gelasert mit LP3

Yi Yu

Customised some swags for work. The Batch button made it a lot quicker!
Settings: nWhite plastic cases: 4,40,1,2

Trinkbecher mit Mustergravur, gelasert mit LP3

Paaj Hnub Haam

Received the LP3 about three days ago. Perfect for engraving stainless steel at 100/100/1!

Logogravur auf der Kupfer, gelasert mit LP3

welaserart

Beautiful brass signage plaques held on a natural wood base. These signs are perfect for businesses, special wedding details or any other special occasion.

Fotogravur auf der Rückseite von iPad, gelasert mit LP3

Mar Ke

The LP3 is absolutely Perfect, i Love it
Settings: 4K/100/23/1

Flask-Set mit Textgravur, gelasert mit LP3

Calvin Forbes

Possibilities are endless with LP3! 4k/100/18/1

Spezifikationen

ProduktnameLaserPecker LP3 Infrarot Lasergravierer
Lasertyp1064nm Infrarot-Laser
LaserleistungDurchschnittliche Leistung: 1W
Spitzenleistung: 10KW
Arbeitsbereich Ellipse: 115 x 80mm
Quadratisch: 65 x 65mm
Graviergeschwindigkeit6 - 800mm/s
Vorschaugeschwindigkeit3750mm/s
Laserpunktgröße0,01mm
Auflösung1K / 2K / 4K
Anwendbare MaterialienDie meisten Metalle, Kunststoffe, Kunstleder und alle Materialien mit Farbbeschichtung
VorschaumodusRechteck-Vorschau / Umriss-Vorschau / Mittelpunkt-Vorschau
SoftwareLaserPecker & LaserPecker Design Space Handyapp & PC Software
Unterstützte DateiformatePC Software: G-Code/JPG/PNG/BMP/SVG/DWG/DXF usw. Vektor Format
Mobile App: JPG/PNG/G-Code/SVG
VerbindungHandy- Drahtlos Bluetooth 5.0+
PC - USB-Anschluss / Drahtlos Bluetooth 5.0+ (Dongle erforderlich)
BetriebssystemHandy - iOS 9.0+ & Android 7.0+
PC - macOS 10+ & Windows 10+
SystemsprachenDeutsch, Spanisch, Französisch, Englisch, Japanisch, Koreanisch, Vereinfachtes Chinesisch, Traditionelles Chinesisch
SicherheitszertifizierungCE, ROHS, FCC, FDA, CDRH, NCC, KC, UKCA, TELEC
StromeingangDC(12V 5A) AC(100-240V, 50-60HZ)
AbmessungenLaserkopf: 168,6 x 62,1 x 169,5mm
Ständer: 194 x 153,5 x 261,1mm

FAQ

Section
Drop element here

Customer Reviews

Based on 28 reviews
82%
(23)
14%
(4)
4%
(1)
0%
(0)
0%
(0)
R
Rojma
Connectivity issues and a weak app, but still a very cool machine

 The LP2 laser engraver is the upgraded model from the LP1, this means that they have completely redesigned the body of the laser itself increasing it's power and accuracy, although they have increased the size of the body itself it's still a really compact unit and the additional handle which has been added to the top as well as the buttons which can be activated and deactivated.So starting from top to bottom as an overview for this entire unit, the handle on top is designed purely for portability in mind, where you can hold the device in your hand and push it up against any surface you need to engrave without having to dismantle anything. The handle is thin and easy to hold making it ideal for lengthy engraving, however i wouldn't want to be the only thing holding it in position during a full engraving as i wouldn't be surprised if you couldn't hold it perfectly still which might affect the engraving itself. Next to the handle are 3 buttons, these buttons by default are turned off and can be turned on through the app by going to the menu button (top right) -->Mode Settings --> Turn Touch Key On. These then allow you to control the preview button and the Power Switch (on/Off). As well as having an indicator light which tells you what's happening with it (yellow flashing whilst synching and Blue solid once connected.In order to use it you'll need to get it connected to the app, in my case i was using a Google Pixel phone which needed to be connected through the device first using the pin 0000 then going through the app and it auto connects, however some phones including iPhones will connect first time directly through the app itself.Once the device is connected which you can check in the menu button and by pressing "Bluetooth Device Connection" you'll then need to set the all important height, this can be done via the buttons on the side of the auto stand or by adding on the Shield (which has an integrated fan) which is the perfect height of 110mm. I tend to use the auto-stand with the shield attached more as i engrave smaller items and just find it that much easier to do it this way.Up to this point you now have a fully functioning single dimension laser engraver...then they had to throw in a 3rd axis which in itself is genius. This add on plugs in relay into the LP2 and allows you to use it numerous ways to engrave more awkward items, the first of them being tubular items such as bottles, pens, pencils etc. Once it has been connected up, you turn on the third axis through mode settings in the app, choose Cylinder and place your item to engrave onto the metal rollers, once you have checked your image and placed it where you want it engraved you can even preview the engraving as it rotates around the object to ensure you get it just right. You can also use this 3rd Axis to turn over, attach the LP2 to and set it up to engrave a longer object in a full run as you watch the LP2 "walk" across it engraving, i would however suggest you do a bit of trial and error on this first though as it is rather more difficult than just standard engraving, you'll also need to make sure it has a fixed run holding it in place either side to ensure a straight engraving.Without going into any more detail, this device is a really fun cool piece of kit that really can engrave most things, it's a marvel how far they have come since the original LP1 making this device the ultimate user friendly laser engraver that works for both pros but also amateurs and enthusiasts.

R
Rojma
Connectivity issues and a weak app, but still a very cool machine

First impressions: Super basic to set up- a manual for both the enclosure and the laser itself are included. The laser assembly is basically two screws to put the two halves of the base together, and then a knob to attach the laser head. The enclosure is four pieces that slot together and then you pop in some locking pins. Doesn't get much simpler.

The footprint is TINY compared to anything else I've used- approximately 10" in each direction. By comparison the footprint on my diode laser is more than 4x bigger. It does of course have a very small engraving area compared to other laser types, but being able to keep it on a corner of my desk for easy access is really nice given that most of my work space is taken up by bulky 3d printers and space on any surface is at a premium.

Now some cons: This only works with their app, which is rudimentary at best. I could not get it to connect to my iPad (does not appear as an available bluetooth device), but it connects fine to my Samsung Galaxy S22 Ultra android phone. You need to register with the app, but it's as simple as requesting a code via email and plugging it in. The app does have a design interface but it is super limited in function and I likely won't use it most of the time. If you're only engraving text and simple stock clipart-type images it's probably fine. Otherwise you'll want to design elsewhere and then import to whatever device you're controlling the laser from. The enclosure is very nice for protecting your eyes, but does nothing to control fumes - so you'll need to address that separately.

The pros: Super easy to scale and line up your projects using the preview feature. It's awesome to be able to clearly see where you're engraving, especially coming from using a diode without a camera and having to guess/eyeball/trial-and-error my alignments most of the time. There are several safety checks you must Ok through on any part of use, many of which are probably less necessary when using with the enclosure (you don't really need the glasses and the laser won't function unless the door is closed). A sample pack of materials and sheet outlining recommended settings are included to get you off and running (which is great because I ordered a bunch of blank charms and such from China that won't be here for a few weeks, and this gave me some starter pieces to fiddle with in the meantime!). Focusing the laser is a snap- you can either use the included ruler or do it visually using the buttons on the stand or even right on your screen in the app (move the laser head up/down by tiny increments until they overlap).

The meh: The letter also says you can get a free bluetooth dongle and cutting plate if you email them. Why not just include them in the package, yall?

I've engraved several of the provided aluminum business cards at different settings- as with any laser you'll want to test different engraving modes and power/depth settings to get the results you want based on your materials and goals. Unfortunately the overly-simple app doesn't seem to have an option for material test patterns (a nice feature on other programs like Lightburn) so you'll have to do these tests manually. I will say that I've had good results so far with the recommended settings provided on the cheat sheet that came with the sample materials, so you can use those as a starting point. Additional resources can be found online and there are a couple of Facebook groups for owners of this laser to compare notes.

Detail on the engravings I've done so far is very good and it's relatively fast. The mandala image I included in the testing pictures was done twice on the same material and scale using the "bin" and "gray" settings to compare results. Bin is much faster and brighter, but gray (the picture setting) gave more accurate detail. For a 1.8" square image the gray setting took just over 11 minutes and the bin setting took just over two- obviously a huge difference for minimal quality gain. I think most projects will be better off with the bin setting (the obvious exception being photographs). I also did some pet tags and found they worked great at 100% power and 5% depth- they were very fast to engrave, about 20 seconds for each side.

If you can get past the limitations of the app this is a really neat machine. I look forward to integrating it into my crafting and jewelry making!

K
Kindle Customer
Great portable laser engraver/cutter.

I'm very impressed by this laser engraver and how much capability it has in spite of such a small footprint. The app is easy to use and the laser engraver quickly and cleanly once you've determined the right settings for the material you're using.There are a few minor improvements that could be made to make it easier to place an item accurately and thus be sure your engraving is straight when using the stand, but nothing that can't be worked around and I still find it to be a 5 star product in spite of this.

N
Nick G
Laserpecker could not be better.

Das Gerät ist super aufgebaut und lässt sich leicht bedienen.Es liefert ein wunderbares Ergebnis wenn man die Höhe der Lasereinheit bei 110mm hat.An der App sollte man noch etwas arbeiten und mehr Beispiele/Vorlage integrieren.

T
The OP
Compact but over performs

Il prodotto è valido, fatto veramente bene sia nella cura dei dettagli che nella sua facilità dell'uso non appena arrivato. Sono pochi pezzi da montare , si scarica l'app con la quale si comanda e manda in "stampa" ed in pochissimo si è già in grado di capire le potenzialità di questo strumento. Si possono scegliere le stampe sui vari tipi di supporto senza timore di sbagliare, i preset sono abbastnza ben curati. Alla fine viene voglia di stampare a laser su qualsiasi cosa. All'interno c'è anche una card con qr per scrivere al supporto clienti, ed è stato bello ricevere in brevissimo tempo una risposta ed avere un contatto di supporto veloce nella risposta ed efficiente. Acquisto consigliato per qualità e serietà del prodotto e del supporto tecnico che gli sta dietro.
